E. M5200/M5300/M5400 Technical Specifications
72A-2570-01 Rev. K 07/2011 E-3
Lead Specifications
Weight M5200: 14.6 lb / 6.6 kg
M5300: 22.5 lb / 10.2 kg
M5400: 13.1 lb / 6.0 kg
Power 115–230 VAC, 50/60 Hz
Current M5200: 1 Amp
M5300: 1 Amp
M5400: 0.5 Amp
Temperature Operating: 0° to 50° C / 32° to 122° F
Storage: –25° to +70° C / –13° to 158° F
Relative Humidity 0–95% non-condensing
Table E.1 Instrument Specifications (Continued)
Feature Definition
Table E.2 Test Lead Specifications
Feature Definition
Test Lead Construction
Integrated three-lead
system in single cable set
Standard ( 362 kV): 60 ft / 18 m
Optional (> 362 kV): 100 ft / 30 m
