3. Setting Up and Running a Test
72A-2570-01 Rev
. K 07/201
1
3
-13
3.
Remove the Isophase or GIS link (
Figur
e
3.20
).
Figure 3.20 Removed Isophase or GIS Link
4.
Apply temporary static-discharge gr
ounds (
Figure
3.21
).
Figure 3.21 Added T
emporar
y S
tatic-Discharge Grounds
5.
Attach the SFRA test leads (
Figure
3.22
).
Figure 3.22 Connected SFRA Leads
SFRA
Instrument
36
38
