72A-2570-01 Rev. K 07/2011 4-1
4. Managing Tests and Templates
This chapter describes the templates provided with SFRA 5.2 and explains
how to use them. It contains the following sections:
• “Introduction” on page 4-1
• “Opening the Template Editor” on page 4-1
• “Creating a New Test Template” on page 4-2
• “Editing or Deleting a Template” on page 4-3
• “Adding, Editing, or Deleting Tests in a Template” on page 4-3
Introduction
SFRA software provides preconfigured templates in the Settings folder. A test
template provides a list of recommended tests for a transformer. You can edit
these template files, replace them, or import other templates using a simple
procedure to merge template files (see “Merging Settings Files”
on page 5-14).
The Template Editor enables you to create, edit, review, and delete test
templates. Test templates are a means of grouping tests for a particular
transformer design and are a flexible way to specify tests for use in the field.
You can associate a template with a number of transformers or create it for
future reference and not associate it with any transformer.
For information about the specific contents of each template, see Appendix B,
“Test Templates.”
Opening the Template Editor
To open the Template Editor:
1. Open the
Edit menu and select Edit Apparatus.
The Test Equipment Editor window opens.
2. Click the
Edit Templates button.
The Template Editor window opens (Figure 4.1 on page 4-2).
