Sweep Frequency Response Analyzer (SFRA) User Guide
5-10 72A-2570-01 Rev. K 07/2011
Test results are date- and time-stamped and saved to the default folder
automatically. You can set up additional data folders based on
transformers, substations, manufacturers, or any other category.
2. To make the folder you select the default folder, click the
Make Folder
Default
button.
3. Click
Browse for Folder.
The Browse For Folder dialog box appears (Figure 5.9 on page 5-9).
4. Navigate to the desired folder.
5. Click
OK.
The files appear in the Data Grid.
6. Click the plus sign to the left of a category in the Data Tree to display the
options for viewing a subset of data in that category.
Click
Refresh Data Tree if you select a new data source or add SFRA
traces to the default folder while the software is open.
To rearrange the order of the columns in the Data Grid, click on a column
head and drag it to the desired location.
7. Select one or more traces to view, using standard Windows commands to
select the rows of interest. (For instructions, see “Data Manager Tab”
on page A-11).
8. Click
Display Traces.
9. View the traces on the Magnitude, Phase, or Impedance tabs.
Export Selected Results to .CSV Files
You can save test files in .CSV format for use in spreadsheets or the M5100
software viewer.
To save test files in .CSV format:
1. Select the file(s) in the Data Manager tab, using standard Windows
commands to select the items of interest. (For instructions, see “Data
Manager Tab” on page A-11)(For instructions, see “Data Manager Tab”
on page A-11).
2. Click
Export Selected Results To CSV Files.
The Files Converted dialog box appears (Figure 5.10 on page 5-11).
