A. Software Overview
72A-2570-01 Rev. K 07/2011 A-9
Help
Table A.5 describes the Help menu options.
Clear Traces Opens the Clear
Traces dialog
box, allowing
you to remove
one or more
traces from the
display. Check
the boxes of the
traces you wish
to remove and
click
OK.
Clearing traces
is different from
checking or unchecking boxes in the Legend pane, which
leaves the trace there but merely shows or hides it on the
tab. Clearing the trace here removes it from the Legend
pane.
Table A.4 Graph Menu Options (Continued)
Command Description
Table A.5 Help Menu Options
Command Description
Help Opens the help file.
About Opens the version information and copyright dialog
box. The software version and build number are in the
upper right corner. If your PC is connected to an
instrument or if you are using an M5300, the
Instrument Firmware Information field displays the
instrument firmware version and related information.
