72A-2570-01 Rev. K 07/2011 E-1
E. M5200/M5300/M5400 Technical
Specifications
This appendix provides specifications for the M5200, M5300, and M5400
instruments. It contains the following sections:
• “Instrument Specifications” on page E-1
• “Lead Specifications” on page E-3
• “PC Requirements” on page E-4
Instrument Specifications
These specifications apply to all three SFRA instruments.
NOTE! Specifications are subject to change without notice.
Table E.1 Instrument Specifications
Feature Definition
Excitation Source
Channels 1
Frequency Range 10 Hz to 25 MHz
Output Voltage 20 V peak-to-peak at 50 ohms
Output Protection Short-circuit protected
Source Impedance 50 ohms
Calibration Interval 3 years
Measurement Channels
Channels 2
