Sweep Frequency Response Analyzer (SFRA) User Guide
4-4 72A-2570-01 Rev. K 07/2011
2. Click the Edit Templates button.
The Template Editor window opens.
3. Click
Manager.
The Test Setting Editor window opens (Figure 4.2 on page 4-3).
The name of each available test appears in the Test Setting List. The
minimum required information is the position of the red lead (e.g., H1, A,
or N) and the black lead (e.g., X0, n, or v). Together, these values provide
the name of the test in the Test Setting List.
Creating a New Test Setting
To create a new test setting:
1. In the Test Setting Editor, click
New.
New Red, New Black appears in the Test Setting List.
2. Enter the appropriate settings. Red Lead and Black Lead are required.
3. Click
OK.
Editing or Deleting a Test Setting
To edit or delete a test setting:
1. In the Test Setting Editor, select the test from the Test Setting List.
2. To delete a test, select it and click
Delete.
The Confirm Delete dialog box appears.
3. Click
Yes.
4. To edit, edit the contents of the fields on the right.
5. Click
OK.
