AssuredSAN 4004 Series Setup Guide 135
1
Weights shown are nominal, and subject to variances.
2
Rail kits add between 2.8 kg (6.2 lb) and 3.4 kg (7.4 lb) to the aggregate enclosure weight.
3
Weights may vary due to different power supplies, IOMs, and differing calibrations between scales.
4
Weights may vary due to actual number and type of disk drives (SAS or SSD) and air management modules installed.
NOTE:
The table below provides comparative information about optional drive enclosures used with 4004
Series controller enclosures. 4004 Series controller enclosures optionally use supported drive enclosures
.
1
Weights shown are nominal, and subject to variances.
2
Rail kits add between 2.8 kg (6.2 lb) and 3.4 kg (7.4 lb) to the aggregate enclosure weight.
3
Weights may vary due to different power supplies and differing calibrations between scales.
4
Weights may vary due to actual number and type of disk drives (SAS or SSD) and air management modules installed.
Environmental requirements
High-capacity controller enclosure (2U48)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
12.7 kg (28.0 lb) [chassis]
23.1 kg (50.9 lb)
34.0 kg (74.9 lb)
High-capacity controller enclosure (4U56)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
14.9 kg (32.8 lb) [chassis]
46.3 kg (102.1 lb)
87.0 kg (191.7 lb)
Table 47 Rackmount compatible drive enclosure weights (ordered separately)
Specifications Rackmount
J6G24 (SFF 2.5" 24-drive enclosure)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
8.6 kg (19.0 lb) [chassis]
16.2 kg (35.8 lb)
22.2 kg (49.0 lb)
J6G12 (LFF 3.5" 12-drive enclosure)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
8.5 kg (18.8 lb) [chassis]
16.1 kg (35.6 lb)
25.6 kg (56.6 lb)
J6G48
(high-capacity 48-drive enclosure SFF 2.5" disks)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
12.7 kg (28.0 lb) [chassis]
20.3 kg (44.8 lb)
31.2 kg (68.8 lb)
J6G56
(high-capacity 56-drive enclosure LFF 3.5" disks)
• Chassis with FRUs (no disks)
1-3
• Chassis with FRUs (including disks)
1- 4
14.9 kg (32.8 lb) [chassis]
45.0 kg (99.1 lb)
85.6 kg (188.7 lb)
Table 46 Rackmount controller enclosure weights (continued)
Specifications Rackmount
Table 48 Operating environmental specifications
Specification Range
Altitude To 3,000 meters (9,843 feet) [2U12/2U24/2U48]
To 1,829 meters (6,000 feet) [4U56]
Temperature* 5ºC to 40ºC (41ºF to 104ºF)
Humidity 10% to 90% RH up to 40ºC (104ºF) non-condensing
Shock 3.0 g, 11 ms, ½ sine pulses, X, Y, Z
Vibration (Shaped-spectrum)
5 Hz to 500 Hz, 0.14 G
rms
total X, Y, Z
