64 Connecting hosts
Four servers/one HBA per server/dual path
Figure 64 Connecting hosts: direct attach—four servers/one HBA per server/dual path (2U)
Figure 65 Connecting hosts: direct attach—four servers/one HBA per server/dual path (4U CNC)
4824/4834/4844
Server 2
0A
0B
Server 1
Server 4Server 3
4524/4534/4544
Server 2
0A
0B
Server 1
Server 4Server 3
6Gb/s 6Gb/s
Server 1Server 2
4854
0A
0B
Server 3Server 4
