66 Connecting hosts

Figure 68 Connecting hosts: switch attach—two servers/two switches (4U CNC)

Four servers/multiple switches/SAN fabric

Figure 69 Connecting hosts: switch attach—four servers/multiple switches/SAN fabric (2U CNC)

6Gb/s 6Gb/s

Switch ASwitch B

4854

Server 2 Server 1

4824/4834/4844

Server 1

Server 2

SAN

Server 3 Server 4
