AssuredSAN 4004 Series Setup Guide 41
1
These compatible product models feature 6 Gbit/s internal disk and SAS expander link speeds.
2
See CNC technology on page 58 for information about locating and installing qualified SFP options into CNC ports.
3
See 12 Gb HD mini-SAS ports on page 59 for information about host connection using SFF-8644 high-density mini-SAS connectors.
4
The 4004 Series 2U12/2U24 and 4U56 enclosures are designed for NEBS compliance; however, the 4004 Series 2U48 and the
3004 Series enclosures are not.
Summary of drive enclosure cabling illustrations
The following illustrations show both reverse and straight-through cabling examples featuring 4004 Series
controller enclosures and compatible J6G56 (4U56), J6G48 (2U48), J6G24 (2U24), and J6G12 (2U12)
drive enclosures. The rear-panel views of the 2U48, 2U24, and 2U12 are nearly identical (the 2U48 PSU
includes a power switch). The rear-panel view of the 4U56 is unique.
NOTE: For clarity, the schematic diagrams show only relevant details such as face plate outlines and
expansion ports. For detailed illustrations, see Controller enclosure — rear panel layout on page 20. Also
see the controller module face plate illustrations that follow the rear panel layout.
Table 5 Summary of cabling connections for 4004 Series enclosures
Model
Form Host connect NEBS
SFF 48 or 24-disk chassis LFF 56 or 12-disk chassis
4824
1, 2
2U24 Qualified CNC option:
FC (8/16 Gb) SFP
10GbE iSCSI SFP
1 Gb iSCSI SFP
Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
4834
1, 2
2U12 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
4844
1, 2
2U48 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
4854
1, 2
4U56 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
4524
1,3
2U24 HD mini-SAS connector:
standard cables
Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
4534
1,3
2U12 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
4544
1,3
2U48 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
4554
1,3
4U56 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
J6G56 4U56 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
J6G48 2U48 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
J6G24 2U24 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
J6G12 2U12 Note 4 mini-SAS to mini-SAS mini-SAS to mini-SAS
Enclosure chassis designators:
4U56: Enclosure measuring four rack units high, providing 56 LFF (3.5") sledded disk drive modules.
2U48: Enclosure measuring two rack units high, providing 48 SFF (2.5") sledded disk drive modules.
2U24: Enclosure measuring two rack units high, providing 24 SFF (2.5") sledded disk drive modules.
2U12: Enclosure measuring two rack units high, providing 12 LFF (3.5") sledded disk drive modules.
See Physical requirements on page 133 for more information about 2U12, 2U24, 2U48, and 4U56 enclosures.
