AssuredSAN 4004 Series Setup Guide 83
Use the SMC or RAIDar to verify any faults found while viewing the LEDs. The SMC and RAIDar are also
good tools to use in determining where the fault is occurring if the LEDs cannot be viewed due to the
location of the system. These web-applications provide you with a visual representation of the system and
where the fault is occurring. The SMC and RAIDar can also provide more detailed information about FRUs,
data, and faults.
Review the event logs
The event logs record all system events. Each event has a numeric code that identifies the type of event that
occurred, and has one of the following severities:
• Critical. A failure occurred that may cause a controller to shut down. Correct the problem immediately.
• Error. A failure occurred that may affect data integrity or system stability. Correct the problem as soon
as possible.
• Warning. A problem occurred that may affect system stability, but not data integrity. Evaluate the
problem and correct it if necessary.
• Informational. A configuration or state change occurred, or a problem occurred that the system
corrected. No immediate action is required.
See the Event Descriptions Reference Guide for information about specific events. See Dot Hill’s Customer
Resource Center web site for additional information: https://crc.dothill.com
.
The event logs record all system events. It is very important to review the logs, not only to identify the fault,
but also to search for events that might have caused the fault to occur. For example, a host could lose
connectivity to a virtual disk or disk group if a user changes channel settings without taking the storage
resources assigned to it into consideration. In addition, the type of fault can help you isolate the problem to
either hardware or software.
Isolate the fault
Occasionally, it might become necessary to isolate a fault. This is particularly true with data paths, due to
the number of components comprising the data path. For example, if a host-side data error occurs, it could
be caused by any of the components in the data path: controller module, cable, or data host.
If the enclosure does not initialize
It may take up to two minutes for all enclosures to initialize. If an enclosure does not initialize:
• Perform a rescan
• Power cycle the system
• Make sure the power cord is properly connected, and check the power source to which it is connected
• Check the event log for errors
Correcting enclosure IDs
When installing a system with drive enclosures attached, the enclosure IDs might not agree with the
physical cabling order. This is because the controller might have been previously attached to enclosures in
a different configuration, and it attempts to preserve the previous enclosure IDs, if possible. To correct this
condition, make sure that both controllers are up, and perform a rescan using the SMC, RAIDar, or the CLI.
This will reorder the enclosures, but can take up to two minutes for the enclosure IDs to be corrected.
To perform a rescan using the CLI, type the following command:
rescan
To rescan using the SMC (v3):
1. Verify that both controllers are operating normally.
2. Do one of the following:
•Point to the System tab and select Rescan Disk Channels.
•In the System topic, select Action > Rescan Disk Channels.
3. Click Rescan.
