SV-EMS-220 Installation and Configuration Chapter
Updates:
Clarified the theory behind and the use of EMS
sensor definition and configuration files in
SkyView.
Added a section regarding SV-EMS-220 wire
harnesses.
Added example engine sensor and transducer
installations.
Removed the requirement for a 200 ohm pull
down resistor in the Rotax oil pressure sensor
installation.
Removed the requirement for a 1.21k ohm pull
up resistor in the Rotax CHT sensor installation.
The SV-EMS-220 is capable of measuring
differential fuel flow. All information in the guide
has been updated to reflect this.
Fixed the fuse call-out on in the Ammeter Shunt
Section. Revision A called out a 7.5 amp fuse. This
guide calls out a 1 amp fuse.
Documented other minor sensor installation
requirements corrections as required.
Clarified SV-GPS-250 installation requirements.
Expanded Appendix C: Wiring and Electrical Connections.
Document number changed to 101320-002.
Minor style changes.
Added information in applicable locations regarding the
SV-NET-SERVO wiring kit.
Color-coded the connectors in the example SkyView
systems figures to indicate gender.
Updated the guide to include HSI requirements and other
related information.
Updated the guide to reflect autopilot functionality,
calibration, and testing information. The most notable
changes are to the Autopilot Servo Installation,
Configuration, and Calibration Section.
Expanded the Input Function Section under the Serial
Port Configuration Section in the SV-D700 / SV-D1000
