- 104
-
Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Transducers and Biopsy
3. Press the left and right side of the clamp as the figure below to attach the bracket to the
transducer firmly.
4. Ensure the bracket is firmly attached, and then place the biopsy needle into the needle guide
path.
BGK-003
Structures:
Clamp
Locking Knob
Needle Guide Holder
