Acclarix LX9 Series Diagnostic Ultrasound System User Manual
Measurements and Reports
No.
Measurement
Group
Measurement
Item
Description
Method
PE to Inf Wall
Pericardial Effusion to Inferior Wall
PE to RV
Pericardial Effusion to Right
Ventricular
PE to RA
Pericardial Effusion to Right
Atrium
1.11
LVM(T-E)
(Left Ventricular
Mass)
LVAd Sax EPi
Left Ventricular Epicardial Area at
Papillary Muscle Level at End
Diastole in Short-axis View
LVAd Sax Endo
Left Ventricular Endocardial Area
at Papillary Muscle Level at End
Systole in Short-axis View
a
Semi-major Axis from Widest
Minor Axis Radius to Apex
d
Truncated Semi-major Axis from
Widest Minor Axis Radius to Mitral
Annulus Plane
1.12
LVM(Cube)
IVSTd
Interventricular Septal Thickness
at End-diastole
LVIDd
Left Ventricular Internal Diameter
at End-diastole
LVPWd
Left Ventricular Posterior Wall
Thickness at End-diastole
1.13
LA/RA
RA Length
Right Atrium Length Diameter
RA Width
Right Atrium Width Diameter
LA Length
Left Atrium Length Diameter
LA Width
Left Atrium Width Diameter
LA Dimen
Left Atrium Dimension
1.14
PISA
MR Rad
Mitral Valve Stenosis Radius
PISA (See
section 8.2.4.2)
MR Als. Vel
Mitral Regurgitation Aliasing
Maximum Velocity
AR Rad
Aortic Valve Stenosis Radius
AR Als. Vel
Aortic Regurgitation Aliasing
Maximum Velocity
TR Rad
Tricuspid Valve Stenosis Radius
TR Als. Vel
Tricuspid Regurgitation Aliasing
