Acclarix LX9 Series Diagnostic Ultrasound System User Manual
8.3.1.4. Growth Curve
Press the <Report> key to enter the Worksheet, and then press the Growth Curve button on the
touch screen to display the Growth Curve Graph. Growth Curve is only available in Obstetric exams.
Growth Curve indicates predicted fetal growth patterns according to the selected reference for a
measurement or calculation. A growth curve graph can display information acquired in the current
exam. Multiple fetus data can be displayed in the same graphic to compare their growth trending
details.
Figure 8-10 Growth Curve Graph
Two radio buttons for displaying single or four growth curve graphs.
If prior exam data have been typed in the Prior Exam Data page,
checking this item here allows you viewing the fetus growth trending on
the growth curve graph. If no prior exam data is typed in, this function is
unavailable.
There is a group of radio buttons to switch fetus, and the growth curve
graph shows data of selected fetus. It is only available in multiple fetus
situations, and the number of enabled button equals current fetus
number which is determined in patient information page.
Fetus All is for displaying the data of all fetus on the same growth curve
graph. Fetus A/Fetus B/Fetus C/Fetus D is for switch the growth curve
graph of different fetus.
Measurement
Item/Reference
For each growth curve graph, there is a drop-down list for selecting
specific measurement or calculation, and a drop-down list for selecting
specific reference of selected measurement or calculation. Selecting
one of them, the growth curve graph will change accordingly.
Check the print items of the growth curve graphs. Press the Print button
on the touch screen to print the selected graphs.
