DHCPv4 Snooping
– 316 –
Default Setting
VLAN-Unit-Port
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
◆ DHCP provides a relay mechanism for sending information about the switch
and its DHCP clients to the DHCP server. DHCP Option 82 allows compatible
DHCP servers to use the information when assigning IP addresses, to set other
services or policies for clients. For more information of this process, refer to the
Command Usage section under the ip dhcp snooping information option
command.
◆ Option 82 information generated by the switch is based on TR-101 syntax as
shown below:
The circuit identifier used by this switch starts at sub-option1 and goes to the
end of the R-124 string. The R-124 string includes the following information:
■
sub-type - Distinguishes different types of circuit IDs.
■
sub-length - Length of the circuit ID type
■
access node identifier - ASCII string. Default is the MAC address of the
switch’s CPU. This field is set by the ip dhcp snooping information option
command,
■
eth - The second field is the fixed string “eth”
■
slot - The slot represents the stack unit for this system.
■
port - The port which received the DHCP request. If the packet arrives over
a trunk, the value is the ifIndex of the trunk.
■
vlan - Tag of the VLAN which received the DHCP request.
Note that the sub-type and sub-length fields can be enabled or disabled
using the ip dhcp snooping information option command.
■
The ip dhcp snooping information option circuit-id command can be
used to modify the default settings described above.
◆ The format for TR101 option 82 is: “<IP> eth <SID>/<PORT>[:<VLAN>]”. Note
that the SID (Switch ID) is always 0. By default the PVID is added to the end of
the TR101 field for untagged packets. For tagged packets, the VLAN ID is always
added. Use the ip dhcp snooping information option remote-id tr101 no-
vlan-field command to remove the VLAN ID from the end of the TR101 field for
Table 60: Option 82 information
82 3-69 1 1-67 x1 x2 x3 x4 x5 x63
opt82 opt-len sub-opt1 string-len R-124 string
