Chapter 21
| VLAN Commands
Configuring Voice VLANs
– 600 –
show voice vlan This command displays the Voice VLAN settings on the switch and the OUI
Telephony list.
Syntax
show voice vlan {oui | status}
oui - Displays the OUI Telephony list.
status - Displays the global and port Voice VLAN settings.
Default Setting
None
Command Mode
Privileged Exec
Command Usage
When the switchport voice vlan command is set to auto mode, the remaining aging
time displayed by the show voice vlan command will be displayed (or “Not Start”
will be displayed). Otherwise, if the switchport voice vlan command is disabled or
set to manual mode, the remaining aging time will display “NA.”
Example
Console#show voice vlan status
Global Voice VLAN Status
Voice VLAN Status : Enabled
Voice VLAN ID : 1234
Voice VLAN aging time : 1440 minutes
Voice VLAN Port Summary
Port Mode Security Rule Priority Remaining Age
(minutes)
-------- -------- -------- --------- -------- -------------
Eth 1/ 1 Auto Enabled OUI 6 100
Eth 1/ 2 Disabled Disabled OUI 6 NA
Eth 1/ 3 Manual Enabled OUI 5 100
Eth 1/ 4 Auto Enabled OUI 6 100
Eth 1/ 5 Disabled Disabled OUI 6 NA
Eth 1/ 6 Disabled Disabled OUI 6 NA
Eth 1/ 7 Disabled Disabled OUI 6 NA
Eth 1/ 8 Disabled Disabled OUI 6 NA
Eth 1/ 9 Disabled Disabled OUI 6 NA
Eth 1/10 Disabled Disabled OUI 6 NA
Console#show voice vlan oui
OUI Address Mask Description
----------------- ----------------- ------------------------------
00-12-34-56-78-9A FF-FF-FF-00-00-00 old phones
00-11-22-33-44-55 FF-FF-FF-00-00-00 new phones
00-98-76-54-32-10 FF-FF-FF-FF-FF-FF Chris' phone
Console#
