Chapter 12
| Link Aggregation Commands
Manual Configuration Commands
– 428 –
router trunk links where traffic through the switch is received from and
destined for many different hosts.
â–
src-dst-mac: All traffic with the same source and destination MAC address
is output on the same link in a trunk. This mode works best for switch-to-
switch trunk links where traffic through the switch is received from and
destined for many different hosts.
â–
src-ip: All traffic with the same source IP address is output on the same link
in a trunk. This mode works best for switch-to-router or switch-to-server
trunk links where traffic through the switch is received from many different
hosts.
â–
src-mac: All traffic with the same source MAC address is output on the
same link in a trunk. This mode works best for switch-to-switch trunk links
where traffic through the switch is received from many different hosts.
Example
Console(config)#port-channel load-balance dst-ip
Console(config)#
channel-group This command adds a port to a trunk. Use the no form to remove a port from a
trunk.
Syntax
channel-group channel-id
no channel-group
channel-id - Trunk index (Range: 1-26)
Default Setting
The current port will be added to this trunk.
Command Mode
Interface Configuration (Ethernet)
Command Usage
â—† When configuring static trunks, the switches must comply with the Cisco
EtherChannel standard.
â—† Use no channel-group to remove a port group from a trunk.
â—† Use no interface port-channel to remove a trunk from the switch.
