Chapter 21
| VLAN Commands
Configuring IP Subnet VLANs
– 590 –
Example
This shows that traffic entering Port 1 that matches the specifications for protocol
group 1 will be mapped to VLAN 2:
Console#show interfaces protocol-vlan protocol-group
Port Protocol Group ID VLAN ID
-------- ----------------- -------
Eth 1/ 2 1 1
Console#
Configuring IP Subnet VLANs
When using IEEE 802.1Q port-based VLAN classification, all untagged frames
received by a port are classified as belonging to the VLAN whose VID (PVID) is
associated with that port.
When IP subnet-based VLAN classification is enabled, the source address of
untagged ingress frames are checked against the IP subnet-to-VLAN mapping
table. If an entry is found for that subnet, these frames are assigned to the VLAN
indicated in the entry. If no IP subnet is matched, the untagged frames are classified
as belonging to the receiving port’s VLAN ID (PVID).
subnet-vlan This command configures IP Subnet VLAN assignments. Use the no form to remove
an IP subnet-to-VLAN assignment.
Syntax
subnet-vlan subnet ip-address mask vlan vlan-id [priority priority]
no subnet-vlan subnet {ip-address mask | all}
ip-address – The IP address that defines the subnet. Valid IP addresses
consist of four decimal numbers, 0 to 255, separated by periods.
mask – This mask identifies the host address bits of the IP subnet.
vlan-id – VLAN to which matching IP subnet traffic is forwarded.
(Range: 1-4094)
priority – The priority assigned to untagged ingress traffic. (Range: 0-7,
where 7 is the highest priority)
Table 115: IP Subnet VLAN Commands
Command Function Mode
subnet-vlan Defines the IP Subnet VLANs GC
show subnet-vlan Displays IP Subnet VLAN settings PE
