Chapter 25

| LLDP Commands

– 771 –

Example

Console#show lldp info statistics

LLDP Global Statistics

Neighbor Entries List Last Updated : 96 seconds

New Neighbor Entries Count : 3

Neighbor Entries Deleted Count : 1

Neighbor Entries Dropped Count : 0

Neighbor Entries Ageout Count : 0

LLDP Port Statistics

Port NumFramesRecvd NumFramesSent NumFramesDiscarded

-------- -------------- ------------- ------------------

Eth 1/1 822 821 0

Eth 1/2 0 0 0

Eth 1/3 0 0 0

Eth 1/4 0 0 0

Eth 1/5 849 862 0

Console#show lldp info statistics detail ethernet 1/1

LLDP Port Statistics Detail

Port Name : Eth 1/1

Frames Discarded : 0

Frames Invalid : 0

Frames Received : 824

Frames Sent : 823

TLVs Unrecognized : 0

TLVs Discarded : 0

Neighbor Ageouts : 0

Console#
