Inlet spool
M588-08-880 Issue D
2Inlet spool
2.1 Description
Refer to Figure 1. Manufactured in both painted carbon steel and stainless steel options (to suit applications) they
are provided to facilitate the fitment of additional accessories and can adapt the pump inlet to an ANSI flange profile.
Figure 1 - Inlet spool
These inlet spools are designed for VACUUM use only, do not pressurise.
Leak test the system after installation and seal any leaks found to prevent leakage of dangerous
substances out of the system and leakage of air into the system.
Warning - hot surface.
