Edwards GXS - M59808002 Carbon Steel Inlet Spool ISO100 - ANSI 4 Inch

© Edwards Limited 2017. All rights reserved. Page 5
Edwards and the Edwards logo are trademarks of Edwards Limited.
Inlet spool
M588-08-880 Issue D
Figure 3 - M59808002 carbon steel inlet spool ISO100 - ANSI 4 inch
Table 2 - M59808002 carbon steel inlet spool ISO100 - ANSI 4 inch check list
Item Qty Description Check
1 1 Gasket 4 inch ANSI x 2.5 thick 
2 1 ISO100 - ANSI 4 inch inlet spool - carbon steel 
3 1 1 inch BSP blanking plug 
4 1 O-ring 35.15 I/D x 3.0 
5 8 M8 x 40 hex head screw - stainless steel 
6 8 M8 washer normal - stainless steel 
73½ inch BSP taper plug 
8 8 M8 washer single coil spring - stainless steel 
