Edwards GXS - M58828004 Inlet Isolation Valve ANSI 6 Inch EPDM

© Edwards Limited 2017. All rights reserved. Page 33
Edwards and the Edwards logo are trademarks of Edwards Limited.
Inlet valve
M588-08-880 Issue D
Figure 26 - M58828004 inlet isolation valve ANSI 6 inch EPDM
Table 26 - M58828004 inlet isolation valve ANSI 6 inch EPDM check list
Item Qty Description Check
1 1 DN150 Bray inlet valve 
2 16 M20 x 140 hex head screw - stainless steel 
3 16 M20 washer normal - stainless steel 
4 8 Studding M20 x 160 mm - stainless steel 
5 16 M20 washer single coil - stainless steel 
- 1 Loom - isolation valve (not shown) 
