Edwards GXS - M58938003 Carbon Steel Inlet Spool ISO160 - ISO160

M588-08-880 Issue D
Page 12 © Edwards Limited 2017. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Inlet spool
Figure 10 - M58938003 carbon steel inlet spool ISO160 - ISO160
Table 9 - M58938003 carbon steel inlet spool ISO160 - ISO160 check list
Item Qty Description Check
1 1 ISO160 trapped O-ring (Fluoroelastomer) 
2 1 ISO160 - ISO160 inlet spool - carbon steel 
34½ inch BSP taper plug 
4 8 M10 x 45 hex head screw - stainless steel 
5 8 M10 washer normal - stainless steel 
6 8 M10 washer single coil - stainless steel 
