Inlet spool
M588-08-880 Issue D
Figure 15 - M58938134 stainless steel inlet spool ISO160 - ANSI 6 inch
Table 14 - M58938134 stainless steel inlet spool ISO160 - ANSI 6 inch check list
Item Qty Description Check
1 1 ISO160 - ANSI 6 inch inlet spool - stainless steel 
24½ inch BSP taper plug 
3 8 M10 washer normal - stainless steel 
4 8 M10 x 45 hex head screw - stainless steel 
5 8 M10 washer single coil spring - stainless steel 
6 1 Gasket 6 inch ANSI x 2.5 thick 
