Inlet valve
3.4.1 Pneumatic connection
For detailed information and guidance on connection of your actuator, refer to the Bray series 92/93 Pneumatic
Actuator Operation and Maintenance Manual.
3.4.2 Electrical connections
3.4.2.1 Installation safety
Be sure to route and secure accessory cables as shown to prevent cables from resting on hot surfaces. Accessory
cables may be damaged if they touch the dry pump, booster and spools during pump operation.
The route for the accessory cable around the GXS enclosure has been chosen carefully to ensure that the cable does
not rest on hot surfaces or pass over other cables carrying mains voltages. When fitting the accessory cable, carefully
follow the instructions given in the sections below. Ensure that cable ties are used as shown to keep the cable in the
correct position.
3.4.2.2 Installing the cables inside the GXS enclosure
1. If the GXS system is running, shut it down.
2. Allow the system to cool sufficiently before moving on to step 3, Minimum one hour.
3. Isolate the GXS system from the electrical supply.
4. Refer to Figure 27 and photo L to identify the external position of the inlet valve on the pump.
5. Remove the top cover from the inlet valve position sensor as show, pass the wires through the cable entry
position on the sensor and connect the wires as shown in photo M.
Terminal 1 - COMMON (RED)
Terminal 2 - OPEN (GREEN)
Terminal 4 - COMMON (RED)
Terminal 5 - CLOSED (YELLOW)
Screw the cable gland into place and tighten until the seal is reached. Replace the top cover.
