Inlet valve
3.3.2 Inlet isolation valve ANSI 6 inch EPDM
Table 32 - Solenoid valve
Parameter Data
Mains Air connection and exhaust ports ¼ inch BSP
Pressure range 2 to 10 bar
Flow rate 950 l/min
Temperature range (Ta) -10 °C to +50 °C
Cable entry PG7 - M16 thread
Voltage 24 V d.c
Table 33 - General
Parameter Data
Description Inlet isolation valve ANSI 6 inch EPDM
Part number M58828004
Mass 30 kg
Table 34 - Butterfly valve
Parameter Data
Description 150 mm (6 inch) valve with undercut disc and bonded
liner suitable for vacuum service
Size 150 mm
Material of Construction
Body Cast iron, Epoxy coated - ASTM A126 Class B
Disc 316 stainless steel - ASTM A351 CF8M
Stem 316 stainless steel - ASTM A276 type 316
Seat EPDM
Maximum design pressure 3.5 bar
Operating temperature range 40 °C to 121 °C
Flange accommodation Multi drilled locating holes
Table 35 - Pneumatic actuator - spring return
Parameter Data
Actuation mode Fail closed
Port connections ¼ inch NPT
Actuator to valve mounting Standard EN ISO 5211
Maximum operating pressure 10 bar
Operating temperature range -40 °C to 95 °C
