Inlet spool
M588-08-880 Issue D
2.2.2 Carbon steel ISO - ISO inlet spools
Figure 7 - M58808003 carbon steel inlet spool ISO63 - ISO100
Table 6 - M58808138 carbon steel inlet spool ISO63 - ISO100 check list
Item Qty Description Check
1 1 ISO100 trapped O-ring seal (Viton) 
2 1 ISO63 - ISO100 inlet spool - carbon steel 
3 1 1 inch BSP blanking plug 
4 1 O-ring 35.15 I/D x 3.0 
5 4 M8 x 40 hex head screw - stainless steel NT 
6 4 M8 washer normal - stainless steel 
7 3 ½ inch BSPT hollow taper plug 
8 4 M8 washer single coil spring - stainless steel 
