Inlet filters
M588-08-880 Issue D
4.3 Technical data
Table 49 - Inlet filter technical data
Description Part Number Material Mass Inlet Outlet Element
Element
Material
Flow rate
m
3
/hr
Carbon steel inlet filter ANSI
4 inch - ISO100
M58808005 Painted
carbon steel
22 kg ISO100 4 inch ANSI A22304363 Polyester 1274
Carbon steel inlet filter ANSI
6 inch - ISO160
M58828005 Painted
carbon steel
55 kg ISO160 6 inch ANSI A22304367 Polyester 1868
Carbon steel inlet filter ANSI
8 inch - ISO200
M59848005 Painted
carbon steel
72 kg ISO200 8 inch ANSI A22304371 Polyester 2548
Stainless steel inlet filter ANSI
4 inch - ISO100
M58808137 Stainless steel 22 kg ISO100 4 inch ANSI A22304365 Polyester 1274
Stainless steel inlet filter ANSI
6 inch - ISO160
M58828137 Stainless steel 55 kg ISO160 6 inch ANSI A22304369 Polyester 1868
Stainless steel inlet filter ANSI
8 inch - ISO200
M59848137 Stainless steel 72 kg ISO200 8 inch ANSI A22304373 Polyester 2548
