Inlet filters
Figure 39 - M59848137 stainless steel inlet filter ANSI 8 inch - ISO200
Table 48 - M59848137 Stainless steel inlet filter ANSI 8 inch - ISO200 check list
Item Qty Description Check
1 1 ANSI 8 inch - ISO200 inlet filter - stainless steel 
2 1 ISO160 trapped O-ring (Fluoroelastomer) 
3 12 M10 full nut - stainless steel 
4 24 M10 washer normal - stainless steel 
5 12 M10 x 80 hex head screw - stainless steel 
