Inlet filters
M588-08-880 Issue D
Figure 38 - M58828137 stainless steel inlet filter ANSI 6 inch - ISO160
Table 47 - M58828137 stainless steel inlet filter ANSI 6 inch - ISO160 check list
Item Qty Description Check
1 1 ANSI 6 inch - ISO160 inlet filter - stainless steel 
2 1 ISO160 trapped O-ring (Fluoroelastomer) 
3 8 M10 full nut - stainless steel 
4 16 M10 washer normal - stainless steel 
5 8 M10 x 70 hex head screw - stainless steel 
