Inlet spool
2.3 Technical data
Table 21 - Inlet spool technical data
Description Part Number Mass
Materials of
Construction
Pump
Connection
Foreline
Connection
Accessory Ports
ISO to ANSI inlet spool - carbon steel
Inlet spool ISO63 - ANSI 4 inch - carbon steel M58808002 10 kg Painted carbon steel ISO63 4 inch ANSI 1 x 1 inch BSP female,
3 x ½ inch BSP female
Inlet spool ISO100 - ANSI 4 inch - carbon steel M59808002 12 kg Painted carbon steel ISO100 4 inch ANSI 1 x 1 inch BSP female,
3 x ½ inch BSP female
Inlet spool ISO100 - ANSI 6 inch - carbon steel M58828002 16 kg Painted carbon steel ISO100 6 inch ANSI 4 x ½ inch BSP female
Inlet spool ISO160 - ANSI 6 inch - carbon steel M58938002 20 kg Painted carbon steel ISO160 6 inch ANSI 4 x ½ inch BSP female
Inlet spool ISO160 - ANSI 8 inch - carbon steel M59848002 25 kg Painted carbon steel ISO160 8 inch ANSI 4 x ½ inch BSP female
ISO to ISO inlet spool - carbon steel
Inlet spool ISO63 - ISO100 - carbon steel M58808138 9 kg Painted carbon steel ISO63 ISO100 1 x 1 inch BSP female,
3 x ½ inch BSP female
Inlet spool ISO100 - ISO100 - carbon steel M59808138 10 kg Painted carbon steel ISO100 ISO100 1 x 1 inch BSP female,
3 x ½ inch BSP female
Inlet spool ISO100 - ISO160 - carbon steel M58828003 13 kg Painted carbon steel ISO100 ISO160 4 x ½ inch BSP female
Inlet spool ISO160 - ISO160 - carbon steel M58938003 15 kg Painted carbon steel ISO160 ISO160 4 x ½ inch BSP female
Inlet spool ISO160 - ISO200 - carbon steel M59848003 19 kg Painted carbon steel ISO160 ISO200 4 x ½ inch BSP female
ISO to ANSI inlet spool - stainless steel
Inlet spool ISO63 - ANSI 4 inch - stainless steel M58808134 10 kg Stainless steel ISO63 4 inch ANSI 1 x 1 inch BSP female,
3 x ½ inch BSP female
Inlet spool ISO100 - ANSI 4 inch - stainless steel M59808134 12 kg Stainless steel ISO100 4 inch ANSI 1 x 1 inch BSP female,
3 x ½ inch BSP female
Inlet spool ISO100 - ANSI 6 inch - stainless steel M58828134 16 kg Stainless steel ISO100 6 inch ANSI 4 x ½ inch BSP female
Inlet spool ISO160 - ANSI 6 inch - stainless steel M58938134 20 kg Stainless steel ISO160 6 inch ANSI 4 x ½ inch BSP female
Inlet spool ISO160 - ANSI 8 inch - stainless steel M59848134 25 kg Stainless steel ISO160 8 inch ANSI 4 x ½ inch BSP female
