Temperature transmitter
Figure 86 - Temperature transmitter assembly - GXS combination (probe length 100 mm)
9.3 Technical data
Table 61 - Thermometer / thermowell
Parameter Data
Material 316L stainless steel
RTD class Std RTD 1 x PT100
Accuracy +/- 1.3 % as stated in DIN 1EC751
Table 62 - Transmitter
Parameter Data
Mounting Head mounted transmitter
Sensor PT100 - 200 °C to 850 °C
Measurement range 0 °C to 200 °C
Model Standard model
