Exhaust silencer
M588-08-880 Issue D
5 Exhaust silencer
The operating procedures detailed in the GXS System Instruction Manual - M588-00-880 must be adhered to, in
particular Section 3 and 5.
All pipe work that is connected to the exhaust silencer must be self supporting and must not create any
misalignment or stress at the connection point to the exhaust silencer.
Before the exhaust silencer is fitted to the pump, the pump must be secured as describe in the
pump manual.
The exhaust silencer must be removed from the pump before the pump can be moved.
This exhaust silencer is designed for ATMOSPHERIC use only; do not pressurise.
Leak test the system after installation and seal any leaks found to prevent leakage of dangerous
substances out of the system and leakage of air into the system.
Can cause muscle strain or back injury. Use lifting aids and proper lifting techniques when
removing or replacing. Refer to Section 5.3 for weight information.
Hot surface.
