Edwards GXS - M58938002 Carbon Steel Inlet Spool ISO160 - ANSI 6 Inch

© Edwards Limited 2017. All rights reserved. Page 7
Edwards and the Edwards logo are trademarks of Edwards Limited.
Inlet spool
M588-08-880 Issue D
Figure 5 - M58938002 carbon steel inlet spool ISO160 - ANSI 6 inch
Table 4 - M58938002 carbon steel inlet spool ISO160 - ANSI 6 inch check list
Item Qty Description Check
1 1 Gasket 6 inch ANSI x 2.5 thick 
2 1 ISO160 - ANSI 6 inch inlet spool - carbon steel 
34½ inch BSP taper plug 
4 8 M10 washer normal - stainless steel 
5 8 M10 x 45 hex head screw - stainless steel 
6 8 M10 washer single coil spring - stainless steel 
