Inlet spool
M588-08-880 Issue D
Figure 19 - Stainless steel inlet spool ISO100 - ISO160
Table 18 - Stainless steel inlet spool ISO100 - ISO160 check list
Item Qty Description Check
1 1 ISO160 trapped O-ring (Fluoroelastomer) 
2 1 ISO100 - ISO160 inlet spool - stainless steel 
34½ inch BSP taper plug 
4 8 M8 x 40 hex head screw - stainless steel 
5 8 M8 washer normal - stainless steel 
6 8 M8 washer single coil spring - stainless steel 
