Exhaust silencer mounting assembly
6.3 Technical data
Table 57 - Silencer mounting technical data
Description Part Number
Carbon Steel
Silencer
Stainless Steel
Silencer
Inlet and outlet
Flow Rate
(Roughing)
m
3
/hr
Attenuation
(at Ultimate
Pressure)
Pressure Test
To
Horizontal silencer mounting -
100 ctr
M58808009 M58808019 M58808031 NW40 150 > 10 dB typical 10 barG
Rear silencer horizontal mounting -
100 ctr
M58808151 M58808019 M58808031 NW40 150 > 10 dB typical 10 barG
Horizontal silencer mounting -
150 ctr
M59838009 M59808019 M59808031 NW50 420 > 10 dB typical 10 barG
Rear silencer horizontal mounting -
150 ctr
M59808151 M59808019 M59808031 NW50 420 > 10 dB typical 10 barG
