Edwards GXS - Silencer Mounting Assembly Storage and Disposal

© Edwards Limited 2017. All rights reserved. Page 77
Edwards and the Edwards logo are trademarks of Edwards Limited.
Exhaust silencer mounting assembly
M588-08-880 Issue D
Figure 57 - M59838163 vertical silencer assembly - 150 ctr
Table 56 - M59838163 vertical silencer assembly - 150 ctr check list
Item QTY Description Check
1 1 iF400 silencer 
21NW50 elbow 
3 2 NW50 trapped O-ring - Viton 9830 / PTFE 
4 2 NW50 clamping ring 
