Edwards GXS - M58828002 Carbon Steel Inlet Spool ISO100 - ANSI 6 Inch

M588-08-880 Issue D
Page 6 © Edwards Limited 2017. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Inlet spool
Figure 4 - M58828002 carbon steel inlet spool ISO100 - ANSI 6 inch
Table 3 - M58828002 carbon steel inlet spool ISO100 - ANSI 6 inch check list
Item Qty Description Check
1 1 Gasket 6 inch ANSI x 2.5 thick 
2 1 ISO100 - ANSI 6 inch inlet spool - carbon steel 
34½ inch BSP taper plug 
4 8 M8 x 40 hex head screw - stainless steel 
5 8 M8 washer normal - stainless steel 
6 8 M8 washer single coil spring - stainless steel 
