Edwards GXS - M59848002 Carbon Steel Inlet Spool ISO160 - ANSI 8 Inch

M588-08-880 Issue D
Page 8 © Edwards Limited 2017. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Inlet spool
Figure 6 - M59848002 carbon steel inlet spool ISO160 - ANSI 8 inch
Table 5 - M59848002 carbon steel inlet spool ISO160 - ANSI 8 inch check list
Item Qty Description Check
1 1 Gasket 8 inch ANSI x 2.5 thick 
2 1 ISO160 - ANSI 8 inch inlet spool - carbon steel 
34½ inch BSP taper plug 
4 8 M10 x 45 hex head screw - stainless steel 
5 8 M10 washer normal - stainless steel 
6 4 M10 washer single coil spring - stainless steel 
