FloBoss 407 Instruction Manual
Rev 5/00 3-47
3.7.6 Discrete Output Relay Module
Specifications
FIELD WIRING
TERMINALS
OUTPUT
OUTPUT
ISOLATION
POWER
REQUIREMENTS
A:
Normally-open contacts
B:
Common
C:
Normally-closed contacts
Type:
SPDT dry relay contact.
Maximum Contact Rating
(Resistive Load):
30 Vdc, 4
Amps; 125 Vac, 4 Amps; 250
Vac, 2 Amps.
Frequency:
0 to 10 Hz maxi-
mum.
Isolation:
10 megohm minimum,
input to output, and input or
output to case.
Voltage:
3,000 Vac (RMS)
minimum, input to output.
12 VDC Version:
4.9 to 5.1 Vdc,
1 mA for module. 12 Vdc, 25 mA
for relay coil (energized) typical.
24 VDC Version:
4.9 to 5.1 Vdc,
1 mA for module. 24 Vdc, 12.5
mA for relay coil (energized)
typical.
VIBRATION
RESISTANCE
SHOCK
RESISTANCE
WEIGHT
CASE
ENVIRONMENTAL
APPROVALS
Functional:
12G, 10 to 55 Hz
@ double amplitude of 2 mm.
Destructive:
21G, 10 to 55 Hz
@ double amplitude of 3.5 mm.
Functional:
20G.
Destructive:
100G.
1.3 ounces (37 grams) typical.
Solvent-resistant thermoplastic
polyester, meets UL94V-0.
Dimensions are 0.6 in. D by
1.265 in. H by 1.690 in. W (15
mm by 32 mm by 43 mm), not
including pins.
Meets the Environmental
specifications of the ROC or
FloBoss in which the module is
installed, including Temperature
and Transient Protection
specifications.
Approved by CSA for hazardous
locations Class I, Division 2,
Groups A, B, C, and D.
