FloBoss 407 Instruction Manual
2-22 Rev 5/00
4.
Save the Event and Alarm logs to disk as explained in Section 7 (or Section 2.9) of the
ROCLINK User Manual. If you have a Measurement Canada FloBoss, also save the Audit
Log to disk. This action clears the audit flags but not the entries, enabling 240 new entries
to come into the Audit Log. The AGA Reports utility also clears the flags when reports are
saved to disk.
5.
Save each Function Sequence Table (FST) program (up to four possible) to disk using the
“Write FST” function in the FST Editor utility of the ROCLINK software. See Section 4.2
of the FST User Manual (Form A4625) for more information.
2.5.3 After Installing Components
After removing power to the FloBoss and installing components as needed, perform the following steps
to start your FloBoss and reconfigure your data. You must use configuration software that is
compatible with the firmware version of the FloBoss 407, as described in Section 1.3.
NOTE
For Measurement Canada units, maintenance and resealing of the FloBoss
must be performed by authorized personnel only.
CAUTION
Ensure all input devices, output devices, and processes remain in a safe state
upon restoring power.
1.
Connect the PWR terminal block to restore power.
NOTE
Due to a cut-out feature designed to avoid draining down the power supply
battery, the FloBoss 407 normally requires a minimum of 12.5 volts to start up.
However, this feature can be bypassed on newer FloBoss 407s by depressing the
LV START switch (see Figure 2-10 on page 2-20) while applying power.
2.
Using the configuration software, check the configuration data (including ROC displays) and
FSTs. If the configuration contained in RAM was lost or corrupted, the configuration contained
in flash memory will automatically be used.
3.
Load or modify the configuration and FSTs as required.
4.
Load and start any user programs as needed. User programs need to be reloaded from their
original disk files as instructed in Section 8 of the ROCLINK User Manual.
