FloBoss 407 Instruction Manual
2-32 Rev 5/00
NOTE
The FloBoss 407 requires a minimum of 12.5 volts to start up. However, a newer
FloBoss 407 can be restarted below 12.5 volts by depressing the LV START switch
(see Figure 2-10 on page 2-20) while applying power.
3.
Using a Flash ROM Extractor, remove the flash ROM chip located at U2 on the
termination board.
4.
Gently press the new flash ROM chip into the socket located at U2 on the
termination board. The flash ROM chip should fit securely into the socket.
5.
Connect the PWR input connector to the processor board.
6.
Refer to Section 2.5.3, After Installing Components on page 2-22.
7.
Refer to the ROCLINK Configuration Software User Manual, which explains how to
load updated firmware and user programs into the flash ROM (if required).
2.5.14 Keypad and Display Replacement
To replace a damaged or faulty keypad or display, contact your Fisher Representative.
2.5.15 Integral MVS Replacement
If an MVS that is integral with a FloBoss 407 needs to be replaced or repaired, contact your Fisher
Representative.
2.6 SPECIFICATIONS
The following pages provide a table of specifications for the FloBoss 407.
