Emerson Fisher FLOBOSS 407

FloBoss 407 Instruction Manual
B-2 Rev 5/00
SIDE VIEW END VIEW
Figure B-1. MVS101R Multi-Variable Sensor
FRONT VIEW SIDE VIEW
Figure B-2. MVS205R Multi-Variable Sensor
Electronics
Head
RTD
Connector
Coplanar
Flange
Sensor Body
Sensor Body
Electronics
Head
