Emerson Fisher FLOBOSS 407 User Manual

FloBoss 407 Instruction Manual
Rev 5/00 3-1
SECTION 3 — INPUT/OUTPUT MODULES
3.1 SCOPE
This section describes the Input/Output (I/O) Modules used with the FloBoss
™
407 Flow Manager and
ROC300-Series products (except ROC306). This section contains the following information:
Information Section Page Number
Product Descriptions 3.2 3-2
Analog Input Loop and Differential Modules 3.2.1 3-3
Analog Input Source Module 3.2.2 3-4
Analog Output Source Module 3.2.3 3-4
Discrete Input Source and Isolated Modules 3.2.4 3-4
Discrete Output Source and Isolated Modules 3.2.5 3-4
Discrete Output Relay Module 3.2.6 3-5
Pulse Input Source and Isolated Modules 3.2.7 3-5
Slow Pulse Input Source and Isolated Modules 3.2.8 3-5
Low-Level Pulse Input Module 3.2.9 3-6
RTD Input Module 3.2.10 3-6
HART Interface Module 3.2.11 3-6
Initial Installation and Setup 3.3 3-7
Calibrating an I/O Module 3.3.1 3-7
Connecting the I/O Modules to Wiring 3.4 3-8
Analog Input Loop Module 3.4.1 3-8
Analog Input Differential Module 3.4.2 3-10
Analog Input Source Module 3.4.3 3-12
Analog Output Source Module 3.4.4 3-13
Discrete Input Source Module 3.4.5 3-14
Discrete Input Isolated Module 3.4.6 3-15
Discrete Output Source Module 3.4.7 3-16
Discrete Output Isolated Module 3.4.8 3-17
Discrete Output Relay Module 3.4.9 3-18
Pulse Input Source Module 3.4.10 3-19
Pulse Input Isolated Module 3.4.11 3-20
Slow Pulse Input Source Module 3.4.12 3-21
Slow Pulse Input Isolated Module 3.4.13 3-22
Low-Level Pulse Input Module 3.4.14 3-23
RTD Input Module 3.4.15 3-24
Calibrating the RTD Module 3.4.15.1 3-24
Connecting RTD Module Field Wiring 3.4.15.2 3-25
HART Interface Module 3.4.16 3-28

Emerson Fisher FLOBOSS 407 Specifications

General

Brand	Emerson
Model	Fisher FLOBOSS 407
Category	Control Unit
Language	English
