FloBoss 407 Instruction Manual
2-34 Rev 5/00
Specifications (Continued)
DIMENSIONS
Overall, FloBoss 407 only:
12.0 in. H by 9.3 in. W
by 4.4 in. D (305 mm by 236 mm by 112 mm).
Overall, with Integral MVS:
18.0 in. H by 9.3 in. W
by 5.1 in. D (457 mm by 236 mm by 130 mm).
Wall Mounting:
2.8 in. W by 12.1 in. H (71 mm by 308
mm) between mounting hole centers. Mounting hole
diameter is 0.37 in. (9.4 mm).
Pipestand Mounting:
Mounts on 2-inch pipe with
U-bolt mounting kit (included).
ENCLOSURE
Die-cast low-copper aluminum alloy with three 0.75 in.
NPT holes in bottom. Single-piece gasketed doors.
Coated with ANSI 61 gray polyurethane paint. Meets
CSA Type 4X rating.
WEIGHT
FloBoss 407:
7 lb. (3.2 kg).
With Integral MVS:
17 lb. (7.7 kg).
APPROVALS
Standard Version:
Approved by CSA for
hazardous locations Class I, Division 2, Groups A,
B, C, and D.
Measurement Canada Version:
Approved by
Measurement (Industry) Canada for gas custody
transfer, in addition to approval by CSA for hazardous
locations (see Standard Version). Note that I/O
Modules must not be used to supply flow inputs to
the FloBoss in a Measurement Canada installation.
