Emerson Fisher FLOBOSS 407

FloBoss 407 Instruction Manual
Rev 5/00 C-3
R1=0
DOC0180A
LEVEL
AO SRC
B
COM
220
C
+V
+I
A
VOLTS
+
-
Figure C-5. Voltage Output — AO Source to Voltmeter
C.4 DISCRETE OUTPUTS TO DISCRETE INPUTS
Figure C-6 shows how to use a discrete output source module to simulate a device transmitting a
discrete voltage level to a discrete input isolated module.
I LIMIT
CONTROL
+5V
+
–
C
B
1 Am
p
N/C
A
C
B
A
+
-
R1=10
N/C
DOC0181A
DI ISO
3.3K
DO SRC
Figure C-6. DO Source Module to DI Isolated Module
Figure C-7 shows how to use a discrete output isolated module to simulate relay contacts to a discrete
input source module.
CONTROL
+5V
DO ISO
N/C
1
NO
COM
C
A
B
C
B
A
–
+
N/C
3.3K
R1=10
DOC0182A
Vs
DI SRC
+
-
Figure C-7. DO Isolated Module to DI Source Module
