FloBoss 407 Instruction Manual
Rev 5/00 2-13
5. Rotate the adapter as required using a padlock shank.
6. Install the padlock.
PADLOCK
COVER
SCREW
PADLOCK
ADAPTOR
RETAINING
WASHER
SIDE VIEW
MAIN COVER SHOWN
OFFSET FOR CLARITY
SHOWN WITH ADAPTOR
AND PADLOCK INSTALLED
FRONT VIEW
MAIN
COVER
Figure 2-3. Padlock Adapter Installation
