FloBoss 407 Instruction Manual
Rev 5/00 5-1
SECTION 5 — DISPLAY AND KEYPAD
5.1 SCOPE
This section describes the FloBoss 407 display and keypad. The display and keypad allows you to
access data and configuration parameters in the FloBoss
™
407 Flow Manager. Topics covered in this
section include:
Information Section Page Number
Product Description 5.2 5-1
Keypad Functions 5.3 5-4
Normal Mode 5.3.1 5-4
Edit Mode 5.3.2 5-4
Alt Mode 5.3.3 5-4
Arrow Keys 5.3.4 5-9
Display of Parameters 5.4 5-9
I/O Summary 5.4.1 5-10
I/O Detail 5.4.2 5-10
Flow Rates 5.4.3 5-10
Flow Comp 5.4.4 5-11
Meter Config 5.4.5 5-11
User List Keys 5.4.6 5-11
Alarms 5.4.7 5-11
Min/Max History 5.4.8 5-12
Minute History 5.4.9 5-13
Hour History 5.4.10 5-14
Day History 5.4.11 5-15
Control 5.4.12 5-16
Comm Ports 5.4.13 5-16
Sys Param 5.4.14 5-16
Help 5.4.15 5-16
Security 5.5 5-17
Logging Off the LCD 5.5.1 5-17
Continually Displaying the Last Parameter 5.5.2 5-17
Troubleshooting and Repair 5.6 5-18
5.2 PRODUCT DESCRIPTION
The display is a 2-line by 20-character liquid crystal display (LCD) visible through the FloBoss 407
enclosure cover. Refer to Figure 5-1. The temperature-compensated display, mounted on the processor
board, allows you to view point configuration parameters and related point data values on-site without
requiring an additional device, such as notebook personal computer (PC).
